Socket: LGA1700
Chipset: Intel B760
Kích thước: Micro ATX Form Factor
Khe cắm RAM: 4 khe DDR5, tối đa 256GB, bus lên đến 7600MHz (OC), hỗ trợ XMP
Khe mở rộng: 1x PCIe 5.0 x16, 2x PCIe 3.0 x1
Lưu trữ: 2x M.2 PCIe 4.0 x4, 4x SATA 6Gb/s, hỗ trợ RAID 0/1/5/10

- Chipset: B760M
- Socket: 1700
- Kích thước: Micro-ATX
- Khe RAM tối đa: 4 khe
- Kiểu RAM hỗ trợ: DDR5
- Hỗ trợ bộ nhớ tối đa: 256GB
- Bus RAM hỗ trợ: 5600 MT/s, 5200 MT/s, 4800 MT/s, 4400 MT/s
- Lưu trữ
4 x SATA 3 6Gb/s, 2 x M.2 NVMe
Kiểu khe M.2 hỗ trợ: M.2 NVMe
- Cổng xuất hình: 1 x HDMI, 1 x VGA/D-sub, 2 x DisplayPort
- Khe PCI: 1 x PCI Express x16; 2 x PCI Express x1
Số cổng USB
+1 x USB Type-C
+3 x USB 3.2( tối đa 5)
- 2 x USB 2.0( tối đa 6)
LAN: 1 x LAN 2.5Gb/s
Âm thanh: Realtek Audio CODEC; High Definition Audio; 2/4/5.1/7.1-channel

✅ Socket: LGA1700 hỗ trợ CPU Intel thế hệ thứ 12, 13 và 14
✅ Kích thước: Micro ATX
✅ Khe cắm RAM: 4 khe (Tối đa 128GB)
✅ Khe cắm mở rộng: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16, 2 x PCI Express x1 slots, supporting PCIe 3.0 and running at x1
✅ Khe cắm ổ cứng: 1 x M.2 connectors, 1 x M.2 connector, 4 x SATA 6Gb/s connectors

• CPU Intel Socket LGA 1151 thế hệ 8 và 9

  ✾ Danh sách hỗ trợ CPU

• Ram DDR4 kênh đôi: ✅ Hỗ trợ DDR4 tối đa 2666 MHz ✅ Mỗi khe ram 16GB hỗ trợ tối đa 32GB
• Cổng xuất hình: ✅ HDMI 1.4 (4096x2160) ✅ VGA (1920x1200) ✅ Tần số quét 60Hz
• Cổng mở rộng: ✅ 1x PCI x16 (PCI Express 3.0 standard) ✅ 2x PCI x1 (PCI Express 2.0 standard)
• Hỗ trợ ổ cứng: ✅ 1x M.2 (2260/2280 SATA and PCIe x2 SSD) ✅ Ổ cứng 2.5 và 3.5: 4x SATA 6Gb/s

  ✾ Danh sách hỗ trợ ổ cứng

• LAN: Realtek® GbE LAN chip (10/100/1000 Mbit)
• Audio: ✅ Realtek® Audio CODEC ✅ High Definition Audio ✅ 2/4/5.1/7.1-channel
• Kích thước: ATX

  ✾ Download Driver và Bios

• AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors
• Chipset: AMD A520
• Bộ nhớ: 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
  Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
• Dual channel memory architecture
• Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
• Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
• Support for Extreme Memory Profile (XMP) memory modules
• Card đồ họa tích hợp:
• Integrated Graphics Processor:
• 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz
• * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
• 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
• * Support for HDMI 2.1 version, HDCP 2.3, and HDR.
• Maximum shared memory of 16 GB
• Âm thanh
• Realtek® Audio CODEC
• High Definition Audio
• 2/4/5.1/7.1-channel
• LAN
  Realtek® GbE LAN chip (1 Gbps/100 Mbps)
• Khe cắm mở rộng" 1 x PCI Express x16 slot, integrated in the CPU:
• Supporting PCIe 3.0 x16 mode
• 1 x PCI Express x1 slot, integrated in the Chipset:
• Supporting PCIe 3.0 x1 mode
• Giao diện lưu trữ
• 1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs:
• Supporting SATA and PCIe 3.0 x4/x2 SSDs
• 4 x SATA 6Gb/s connectors, integrated in the Chipset:
• Supporting for RAID 0, RAID 1, and RAID 10
• CPU: 4 x USB 3.2 Gen 1 ports on the back panel
• Chipset:
• 2 x USB 3.2 Gen 1 ports available through the internal USB header
• 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
• Kết nối I/O bên trong
• 1 x 24-pin ATX main power connector
  1 x 8-pin ATX 12V power connector
  1 x CPU fan header
  1 x system fan header
  1 x M.2 Socket 3 connector
  4 x SATA 6Gb/s connectors
  1 x front panel header
  1 x front panel audio header
  1 x USB 3.2 Gen 1 header
  1 x USB 2.0/1.1 header
  1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
  1 x Clear CMOS jumper
• Kết nối bảng phía sau
• 1 x PS/2 keyboard/mouse port
  1 x DisplayPort
  1 x HDMI port
  4 x USB 3.2 Gen 1 ports
  2 x USB 2.0/1.1 ports
  1 x RJ-45 port
  3 x audio jacks
