Linh Kiện Máy Tính

• AMD Socket AM4, support for: AMD Ryzen™ 5000 Series/ Ryzen™ 5000 G-Series/ Ryzen™ 4000 G-Series and Ryzen™ 3000 and Ryzen™ 3000 G-Series Processors
• Chipset: AMD A520
• Bộ nhớ: 4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory
  Support for DDR4 4733(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules
• Dual channel memory architecture
• Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules
• Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
• Support for Extreme Memory Profile (XMP) memory modules
• Card đồ họa tích hợp:
• Integrated Graphics Processor:
• 1 x DisplayPort, supporting a maximum resolution of 5120x2880@60 Hz
• * Support for DisplayPort 1.4 version, HDCP 2.3, and HDR.
• 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz
• * Support for HDMI 2.1 version, HDCP 2.3, and HDR.
• Maximum shared memory of 16 GB
• Âm thanh
• Realtek® Audio CODEC
• High Definition Audio
• 2/4/5.1/7.1-channel
• LAN
  Realtek® GbE LAN chip (1 Gbps/100 Mbps)
• Khe cắm mở rộng" 1 x PCI Express x16 slot, integrated in the CPU:
• Supporting PCIe 3.0 x16 mode
• 1 x PCI Express x1 slot, integrated in the Chipset:
• Supporting PCIe 3.0 x1 mode
• Giao diện lưu trữ
• 1 x M.2 connector, integrated in the CPU, supporting Socket 3, M key, type 2280 SSDs:
• Supporting SATA and PCIe 3.0 x4/x2 SSDs
• 4 x SATA 6Gb/s connectors, integrated in the Chipset:
• Supporting for RAID 0, RAID 1, and RAID 10
• CPU: 4 x USB 3.2 Gen 1 ports on the back panel
• Chipset:
• 2 x USB 3.2 Gen 1 ports available through the internal USB header
• 6 x USB 2.0/1.1 ports (4 ports on the back panel, 2 ports available through the internal USB header)
• Kết nối I/O bên trong
• 1 x 24-pin ATX main power connector
  1 x 8-pin ATX 12V power connector
  1 x CPU fan header
  1 x system fan header
  1 x M.2 Socket 3 connector
  4 x SATA 6Gb/s connectors
  1 x front panel header
  1 x front panel audio header
  1 x USB 3.2 Gen 1 header
  1 x USB 2.0/1.1 header
  1 x Trusted Platform Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)
  1 x Clear CMOS jumper
• Kết nối bảng phía sau
• 1 x PS/2 keyboard/mouse port
  1 x DisplayPort
  1 x HDMI port
  4 x USB 3.2 Gen 1 ports
  2 x USB 2.0/1.1 ports
  1 x RJ-45 port
  3 x audio jacks

✅Dung lượng: 16GB (1x16GB) DDR5
✅Tốc độ bus: 5600MHz CL40
✅Điện áp: 1.35V
✅Tản nhiệt: Có
✅Led: Không

✅ Model: CP-9020278-NA
✅ Công suất tối đa: 650W
✅ Hiệu suất: 80 Plus Bronze
✅ Cáp rời: không hỗ trợ
✅ Chuẩn kích thước: ATX
✅ Số cổng cắm: 3 x SATA, 1 x 24-pin Main, 2 x 8-pin (6+2) PCIE, 1 x 8-pin (4+4) EPS, 2 x PATA
✅ Quạt làm mát: 1 x 120 mm
✅ Nguồn đầu vào: 100 - 240VAC

• Model: AcBel I-power G700.
• Công suất tối đa: 700W.
• Số cổng cắm: 1 x 24-pin Main, 1 x 8-pin (4+4) EPS, 2 x 6-pin PCIE, 4 x 8-pin (6+2) PCIE, 4 x Peripheral (4-pin), 4 x SATA.
• Hiệu suất: 80 Plus White.
• Quạt làm mát: 1 x 120 mm.
• Nguồn đầu vào: 200 - 240VAC

✅ Chủng loại: Bộ nhớ trong
✅ Hãng sản xuất: Corsair
✅ Series: VENGEANCE® LPX
✅ Loại RAM: DDR4
✅ Đóng gói: 16GB (1x16GB)
✅ Bus: 3600MHz
✅ Điện áp: 1.35V
✅ Tản nhiệt: Nhôm truyền thống
